Dormakaba ED100LE - Mounting Plate Attachment to Jamb or

24
ED100LE 02-2021DL4616-001
dormakaba ED100LE operator – Fine cover
Installation Instructions
Chapter 8
NOTICE
Optional full width cover installation.
Reference Appendix A for mounting plate
extension installation.
.. Fasten mounting plate to jamb and/or wall.
CAUTION
Conduit box (if used):
• Insure conduit box or plate is prepared with
applicable conduit fitting or cord grip.
• Insure jamb or wall is prepared for wiring
to conduit fitting or cord grip.
. Select applicable installation template.
NOTICE
Installation templates.
• Reference Chapter  – Installation
Templates.
. Using template as a guide, locate mounting plate on
door frame/wall and prepare twelve mounting holes
for mounting plate fasteners.
CAUTION
• Select fasteners based on door frame and
wall material.
• Use fasteners provided with EDLE
(Fig. ..).
• Use appropriate wall anchors if required.
. Fasten mounting plate to door frame and/or wall.
.. Mounting plate installation checks.
NOTICE
Installation checks.
• Check level.
• Check spindle to hinge centerline distance.
• Check alignment.
.. Install third guide pin.
. Install third guide pin (Fig. .., ..) in mounting
plate.
• Use  mm hex T-handle or hex key.
Fig. 8.4.1 Mounting plate installation
1 ED100 mounting
plate
2 Mounting hole
3 Guide pin
. Mounting plate attachment to jamb or wall
(12) 23
1
Fig. 8.4.2 Mounting plate installation with conduit box
3
1
(12) 2
4
1 ED100 mounting
plate
2 Mounting hole
3 Guide pin
4 CB conduit box
13
13 Guide pin
Fig. 8.4.4 Guide pin
Fig. 8.4.3 ED100LE mounting
plate screw pack
HK4053-010
7 #12 x 2 1/2" Phillips
FHWS
DF0670 000
Quantity 12
8 1/4-20 x 1 1/2"
PFHMS
DF0671-000
Quantity 12
1
2
