ED100LE 02-2021DL4616-001
dormakaba ED100LE operator – Fine cover
Installation Instructions
Chapter 16
Fig. 16.1.1 ED100LE Companion pull
. EDLE Companion installation templates
ED100LE COMPANION PULL
9/16”
[13.5]
FIXED
5 3/4”
[146.32]
Axle center line
17 3/4”
[450]
9 1/8”
[231]
Centerline of
hinge pin
A
A
9/16”
[13.5]
FIXED
10 3/4”
[272.50]
Centerline of
hinge pin
B
Axle centerline
17 3/4”
[450]
10 1/2”
[267.5]
B
Cover length = centerline of hinge pin - 1 1/8” [28.5]
Cover and axle end are fixed and cannot be extended
Track height
(from bottom of cover)
1 1/4” [31.7] with 1/2” [12] pivot pin
1 5/8” [41.3] with 1” [25] pivot pin
Track height
(from bottom of cover)
1 1/2” [38.1] with 1/2” [12] pivot pin
2” [50.8] with 1” [25] pivot pin
Section A-A
Operator side
Section B-B
Closer side
Reveal
0 - 2 1/4” [57]
5 1/8”
[129]
Axle distance
(Bottom of arm
aligns to bottom
of cover)
2 3/4”
[70]
Reveal
0 - 2 1/4” [57]
5 1/8”
[129]
2 3/4”
[70]
Axle distance
(Bottom of arm
aligns to bottom
of cover)
Axle extension
Pull axle
distance
13/16” [20] 1 5/8” [41]
2 3/8” [60]
3 1/8” [81]
 Companion door installation
