Dormakaba ED100LE - Install 8816 Closer on Backplate - Pull Arm Mounting

49
ED100LE 02-2021DL4616-001
dormakaba ED100LE operator – Fine cover
Installation Instructions
Chapter 18
1 Backplate, ED
operator
companion
DC3468-0502
Companion closer
adapter
DC3468-070
3 #4 x 1/4-20 x 5/8"
Philips flat head
screw
DF0399-00G
4 1/4-20 x 1" Philips
FHMS undercut
DF3101-01Z
5 Door closer, 8816
08210970
Fig. 18.2.3 Closer adapter and closer assembly mounting to backplate – pull arm application
.. Install  closer for pull arm application.
NOTICE
Verify closer spring size prior to installation.
NOTICE
PULL (T) mounting holes.
For pull arm application, use
PULL (T) mounting holes (Fig..18.2.3)
. Install  closer on backplate – pull arm mounting
3 #4 x 1/4-20 x 5/8"
Philips flat head
screw
DF0399-00G
(8) 4
Fig. 18.2.1 Companion screw kit
HK4607-001
(4) 3
Fig. 18.2.2 Companion closer
adapter fasteners
4 1/4-20 x 1" Philips
FHMS undercut
DF3101-01Z
1
2
3
PULL (T)
(4) 4
(4) 5
PUSH (J)
PULL (T)
Fig. 18.2.4 Closer adapter and closer assembled to backplate
PUSH (J)
