ED100LE 02-2021DL4616-001
dormakaba ED100 low energy operator – Fine cover
Installation Instructions
Appendix A
3
3.1
Fig. A.1.5 Professional cover bracket
3 Professional cover
bracket
HC3481-010
3.1 Bracket collar
2 Mounting plate
extension
3 Professional cover
bracket
HC3481-010
2
3
Fig. A.1.6 Install cover bracket
Fig. A.1.7 Cover bracket installed
A.. Install cover bracket.
. Insert cover bracket collar into mounting
plate groove at an angle (Fig. A.)
. Rotate cover bracket parallel to
mounting plate extension.
. Position bracket under set of M screws
and washers at end of extension.
