Description
10 10099206-AA
Main Components
The main components of the SmartDate X65 are:
Optional Components
Your SmartDate X65 may have been supplied with optional components, the most common of
which are:
Encoder: For tracking the speed of
the lm in continuous applications
IP45 Kit: For protection against
water ingress
Beacon Tower: To monitor the
operational state of the printer
1
2
3
Printer body
Containing the drive system
and thermal transfer
printhead
Controller
Containing the main operation
PCBs and capacitive
touchscreen user interface
Ribbon cassette
Containing ribbon supply and
waste take up spools
