Printer conguration
63 10099206-AA
12 07 2021
SPAIN
ES12200C00
12 07 2021
12 07 2021
12 07 2021
SPAIN
SPAIN
SPAIN
12mm
ES12200C00
ES12200C00
ES12200C00
Number of prints
possible in the print area
In this example ‘Step Distance’ is 12mm and ‘Step Repeat’ is 2.
Relative Motion Printing
This feature is available on the combined version of the SmartDate X65 when working in
continuous mode and allows the printer to nish a print that has been interrupted during the print
cycle.
Tools > Settings > Printer > Printing > Print Features
Max Substrate Speed
Print Features
300 mm/s
70
0.0
800
No Ribbon Save
High Pack Rate
Min Print Speed
Print Mode
Relative Print Max Travel
Return Speed (mm/s)
Ribbon Save Mode
If the measured substrate speed falls to below the minimum set value during the print cycle,
the printhead carriage will move forward, up to a maximum of 30mm from its xed position, to
complete the print.
Setting Value Description
