Interface
29 10099206-AA
Other Screens
There are a number of other screens that may occasionally appear. Generally they are designed
to give advice or conrm an action. This example is displayed after a new ribbon is loaded.
New Ribbon Detected
Please conrm or amend the ribbon settings:
Grade: Xtra 3520
Colour: Black
Width: 53mm
Dead Dot Display
When enabled this feature provides a visual indication of failed printhead elements in the print
preview on the ‘Home’ screen. The failed elements are displayed by a red line or a series of red
lines running through the print.
15/10/2020
Start
96 %
Tools
O
110
Select Job
Adjust
11:56
Administrator
default job
Idle
Total print count
5904
Batch print count
Current Substrate Speed
Instant Average Pack Rate
0
22
Use By
19th May 2022
Packed in UK
The ‘Print Adjust’ feature can be used to optimize the print position by moving the image on the
canvas, avoiding the failed elements and maximizing printhead use.
