Installation
12 10099206-AA
Controller and Printer Connection
Connection Panels
The connection panels are shown below. The connectors used will depend on the printer type
and conguration.
Controller
1. Printer Power and Signals
2. I/O
3. RS232 Comms.
4. USB ‘A’
5. Ethernet
6. USB ‘B’
7. Mains
Printer and ribbon cassette
1. Printer Power and Signals
2. Encoder
3. Compressed Air
1
2
3
4
5
6
7
1
2
3
