136 10099206-AA
3
Disconnect the power connector from the
Printhead
4
Pull the printhead from the print module
Fitting the New Printhead (128 mm Printer)
1
Line up the prinhead with the printhead
guide
2
Press the printhead to the home position
towards the peel roller
Maintenance
