Dover markem-image SmartDate X65 User Manual

Technical specications
138 10099206-AA
 Machine Specication
 SmartDate X65
Printhead Resolution 300 dpi (12 dots/mm).
Power Supply 90 - 264V 47 - 63 Hz
IP Rating
Controller IP 41
Printer IP 2X
Environmental
Operating temperature:
0° C to 40° C (32° F to 104° F)
Air Supply
6 bar / 90 psi (maximum) dry,
uncontaminated.
Controller Dimensions
210 mm (7.67”) High x 304 mm (10.3”) width x 130 mm (4.5”)
Allow a minimum of 100 mm (3.15 ”) for the connector and cable access to
both printer and controller.
Controller Weight 4.5 kg
Noise Levels
Test Standard BS EN ISO 3746:1996
199 ppm with a 10 mm Image
(700 mm/s) <70 dB (A)
Air Consumption Min. 0.4 ml/print @ 2.5bar
Ribbon Colours
An extensive range of approved Markem-Imaje ribbons are available
including Black, White and a selection of other colours. Only Markem-
Imaje approved ribbon types must be used to enable / maintain / and
sustain the quality / adhesion / performance of the printer.
Font Styles Any True Type font. + Speedo and TI Corpus Christi
Font Sizes Scalable to specic point sizes.
Orientation Any mix of orientation.
Barcodes
Code 39, EAN 8, EAN 13, EAN 128, UPC A and UPC E, RSS-14 QR,
RSS-Expanded
Graphics Lines, boxes and logos (*.bmp format)
Special Functions
Automatic Real Time, Date, Batch and Shift Information. Automatic ‘Best
Before End’ offset calculation and coding. Incremental alphanumeric text
and barcodes.
Local SmartDate Memory 30Mb.
Machine Interface
Inputs: ‘Print’ input signal status.
Outputs: Interlock Output
User Congurable I/O
Operator Interface
Wipe Clean touchscreen for a local entry of variable information, complete
with Full Diagnostics capability.
