156 Instructions for use | Atlan A300, A300 XL, A350, A350 XL SW 1.0n

Alarms

There are 2 options for downgrading or clearing the alarms:

Option 1:

Option 2:

3600836011

Option 1 Option 2

Touch the ALARM RESET button (1) in

the header bar and confirm.

In the Alarms > Current alarms

dialog (2), touch the Reset all button (3)

and confirm.

All the alarms displayed in the alarm

message field will be downgraded or

reset.

All alarms will be downgraded or reset.
