Page 7-10 Infinity Gamma Series VF4
The printout is identified by the following:
! Patient name and ID.
! Bed label and Care Unit.
! Date and time of the recording request.
! Recording delay and speed.
! Monitored parameters and values.
! Crossed bell symbol for parameters whose alarm is disabled.
! Recording mode (timed or continuous).
! *** or blanks if numeric values and waveforms are unavail-
able.
The printout shows the top two waveforms that were displayed on
the monitor’s screen at the time of the print request. A small black
marker along the bottom of the printout indicates the time of the
print request.
NOTES:
! If the second waveform channel is set to Cascade, only the
waveform in the first waveform channel prints out.
! OCRG recordings cannot be printed on a laser printer.
