Dräger Infinity Gamma Series

Technical Data
VF4 Infinity Gamma Series Page D-3
Basic System Components
Monitor — Base Unit
Dimensions Gamma: 196 mm height (7.7 in)
249 mm width (9.8 in)
134 mm depth (5.3 in)
Gamma XL: 196 mm height (7.7 in)
267 mm width (10.5 in)
147 mm depth (5.8 in)
Weight
(without etCO
2
)
Gamma: 3.42 kg (7.54 lb) with lead acid battery
3.22 kg (7.10 lb) with lithium ion battery
2.87 kg (6.32 lb) without battery
Gamma XL: 3.87 kg (8.54 lb) with lead acid battery
3.67 kg (8.10 lb) with lithium ion battery
3.32 kg (7.32 lb) without battery
Materials Plastics: ABS, FR 110
Printed Circuits: glass/epoxy, lead/tin solder, copper
etch, lithium battery
Battery: sealed lead acid, or lithium ion (option)
Heatsink: cast aluminum
NBP assembly: silicon tubing, steel, copper wire
Packing: corrugated cardboard, urethane foam
Disposal All materials must be disposed of or recycled properly
and in accordance with local regulations. There are no
known special disposal requirements for any accesso-
ries.
Battery Pack Lead Acid: PANASONIC LC-T121R8PU or equivalent
Li-ion: Dräger Li+ Battery Pack
Protection Class Internally powered, for use with specified Class I power
supply
Mode of Operation Continuous (with external source of power via AC
adapter, CPS, or IDS).
DC Input 11 – 14 VDC, 2.5A
Battery Operating Time
(NBP measurements every 15
minutes, no etCO
2
, at 25°C)
Lead acid: 75 minutes
Lithium ion: 180 minutes
Battery Recharging
Time
Lead acid: 5½ hours, typical.
Lithium ion: 8 hours, typical.
