End-Tidal CO2
VF4 Infinity Gamma Series Page 13-15
Measuring Mode
Configure the etCO
2
pod for mainstream or sidestream monitor-
ing as follows.
STEPS: Selecting the Measuring Mode
1. Click on the etCO
2
parameter box.
2. Click on
More...
3. Click on Meas. Mode.
4. Select the desired measurement mode (
Main or Side) and
click the knob.
Anesthetic Agent Compensation
The monitor allows the user to adjust the etCO
2
detection to com-
pensate for expired and inspired anesthetic agents in the patient’s
air supply. Failure to compensate for anesthetic agents results in
inaccurate measurement values. Available compensation settings
are:
! 0% to 20%, in increments of 1% (default 0%).
NOTE: If you set the Expired field, the Inspired field automati-
cally adjusts to an appropriate value. However, if you set the
Inspired field, the Expired field does not change.
