Multigas
VF4 Infinity Gamma Series Page 14-5
NOTES:
! The presence of organic cleaning solutions or gases containing
freon may adversely impact the accuracy of the Scio module.
! Mechanical shocks during the measurement or the presence of
other paramagnetic agents can distort measured values of oxy-
gen concentration.
! The Scio module is self-zeroing and does not need routine cali-
bration by the clinical staff. However, a yearly check of the
Scio calibration components should be performed by autho-
rized technical personnel.
! To ensure safety, the Scio module requires routine cleaning.
For instructions see the appendix Cleaning, Disinfecting, Ster-
ilizing.
External Power Indicator
Fan Filter
Exhaust Port
Connector for
Scio Module: Front and Rear Panels
Water Trap
External Power Supply
To Next Page
