Page 14-10 Infinity Gamma Series VF4
NOTES: The following display/monitoring restrictions apply in
the OR mode:
! The ST parameter box is not available and deviations in the ST
segment are neither monitored nor saved in the trend storage.
! The NBP parameter box is only available when two ECG
waveforms occupy the top two waveform channels. In this
case, the NBP parameter box is displayed next to the second
ECG waveform. If the NBP parameter box is not displayed,
you cannot take NBP measurements.
! In OR mode, the etCO
2
waveform is always displayed in the
bottom waveform channel to the left of the CO
2
parameter box.
You cannot change this location nor select a different bottom
channel display. In OR mode, the menu selection Bottom
Channel therefore does not appear in the Main Screen or Fast
Access menus.
