Invasive Blood Pressure
VF4 Infinity Gamma Series Page 16-5
STEPS: Selecting the IBP Display Channel and
Waveform Amplitude
1. Click on the desired waveform channel.
2. Click on
Waveform.
3. Select the desired pressure parameter and click the knob.
4. Click on
Size.
5. Select the desired display amplitude and click the knob.
NOTE: The Channel setup menu makes only those pressure labels
available which have been selected for the monitoring session in
the IBP setup menu (or the default GP1/GP2).
