Dräger Infinity Gamma Series

Page D-8 Infinity Gamma Series VF4
Infinity Docking Station (IDS) Power Supply
(55 84 912 E530U and 59 49 271 E530U)
Connections AC Power Connector, DC Power Cable/Connector,
Potential Equalization Conductor
Cooling Convection
Dimensions 135 mm (w) x 111 mm (d) x 270 mm (h)
(5.3” x 4.4” x 10.6”)
Without mounting bracket the depth is 71 mm (2.8”).
Weight 1.85 kg (4.1 lbs)
Input Voltage Range 55 84 912 E530U: 100-120 VRMS, 200 - 240 VRMS
59 49 271 E530U: 200-240 VRMS
Mains Frequency 50/60 Hz
Power Consumption 55 84 912 E530U: 3.4 A
59 49 271 E530U: 1.6 A
Power Output +13 VDC, 10.8 Amps
Protection Class Class I
Chassis leakage current <300
µ
A @120VAC, <500
µ
A @220VAC
Mode of Operation Continuous
Ingress Protection Ordinary
Environmental Require-
ments
Temperature:
(operating:) 10 to 40 °C (50 to 104 °F)
(storage:) -40 to 70 °C (-40 to 158 °F)
Relative Humidity:
(operating:) 20 to 95%, non-condensing
(storage:) 10 to 95%, with packaging
Atmospheric Pressure:
(operating:) 525 to 795 mmHg (70 to 106 kPa)
(storage:) 375 to 795 mmHg (50 to 106 kPa)
Note that 55 84 912 E530U is for use with input voltage range of 100-120 VRMS,
and 59 49 271 E530U is for use with input voltage range of 200-240 VRMS.
