Monitor Setup
VF4 Infinity Gamma Series Page 2-3
STEPS: Connecting the AC Adapter
1. Connect the AC adapter's cable to the DC input on the moni-
tor’s back panel.
2. Connect the power cord to the AC adapter.
3. Plug the other end of the power cord into a hospital-grade
outlet. The battery charge indicator on the front panel lights
up.
4. Press the
Power fixed key and wait until the display lights up
and the monitor completes its self-test.
If the monitor does not power on, verify the connections and
retry. If it fails again, take the unit out of operation and contact
DrägerService.
WARN IN G: If the outlet or ground conductor is sus-
pect, operate the monitor with a battery.
