100 Technical Manual | Dräger Polytron
®
8000 Series
Performance Approvals
NOTICE
Sensor failure
The sensor cannot be used for Oxygen measurements in the presence of Helium!
Do not use the sensor for Oxygen measurements in the presence of Helium.
CAUTION
Sensor failure
The exposure to higher concentrations of unsaturated hydrocarbons, alcohols or
hydrogen over an extended period of time (dose approx. 100,000 ppm x hours)
could cause the sensor to fail.
Ensure that the sensor is not exposed to such concentrations over an extended
period of time.
Stabilization time: 5 x t
0...90
Measuring range
0-5...25 Vol% O
2, 0-25 Vol% O2
Default: 25 Vol% O2
Minimum reading: -1.25 Vol% O2
Warm-up time
Operation: 20 minutes / Calibration: 6 hours
20.4 FM Performance Approval for DrägerSensor H2S and
H
2S LC
The DrägerSensor H2S and H2S LC are electrochemical diffusion sensors
measuring hydrogen sulfide (H
2S) in ambient air.
Humidity No influence Relative deviation from read-
ing at 50 % r.H.:
< 2.5 % of measurement
value
Response time
t0...20 t0...90
0-5 Vol% O2
14 seconds
1)
1) Response time is higher than the permissible limit of EN 50104.
45 seconds
0-25 Vol% O
2 10 seconds 27 seconds
Influence of environmental parameters
Zero point Span
DrägerSensor H2S (6810435)
Examination Type P8100 ETR 0400, 0401, 0500, 0501
Interface
1)
4-20mA, relay
Environmental parameters
Humidity 5 to 95%RH, non-condensing
