Dräger Polytron 8000 Series Technical Manual

Technical Manual | Dräger Polytron
®
8000 Series 83
Factory default settings
15.3.2 Polytron
®
8100 EC
Hydride SC 6809980 0.3 1 1 0.1 0.2
HCN 6809650 10 50 50 10 20
HCN LC 6813200 5 50 50 4 8
NO
2 6809655 5 10 100 2 4
NO
2 LC 6813205 1 5 20 0.5 1
SO
2 6809660 5 10 100 2 4
CI2 6809665 1 10 50 0.5 1
H
2O2 LC 6809705 1 5 300 1 2
H
2O2 HC 6809675 1000 4000 7000 200 2800
H
2 6809685 500 1000 3000 200 400
COCI2 6809930 0.1 1 20 0.1 0.2
Hydrazin 6810180 0.3 1 5 0.1 0.2
HCI SC 6809640 20 30 100 5 10
AC 6810595 3 10 30 2.5 5
PH3/AsH3 6809695 0.3 1 20 0.1 0.2
NH3 HC 6809645 300 1000 1000 50 100
NH3 LC 6809680 50 100 300 12.5 25
NH3 FL 6813260 50 100 300 12.5 25
NH3 TL 6813095 50 100 300 12.5 25
NH3 TH 6800055 300 1000 10000 50 100
Ozon 6814005 0.5 1 5 0.1 0.2
Sensor Part number
Range Default value
Min. Default Max. A1 A2
Menu Default setting Range
A1 Alarm Depending on
the sensor
A2 Alarm Depending on
the sensor
Hysteresis for A1
alarm at direc-
tion rising
00 to A1
Hysteresis for A2
alarm at direc-
tion rising
00 to A2
Calibration inter-
val [days]
Depending on
the sensor
0 to 720
Display capture
offset
20.9 Vol% (O2) 0 to 25 Vol% (O2 LS)
0 to 100 Vol% O
2)
Display capture
low
-0.25 Vol% (O2) 0 to -0.75 Vol%
Display capture
high
0.25 Vol% (O2) 0 to 0.75 Vol%
Full scale deflec-
tion
25 Vol% (O2,
O
2LS)
5 to 25 Vol% (O
2 LS)
5 to 100 Vol% O
2)

Dräger Polytron 8000 Series Specifications

General

Ingress Protection	IP66/67
Detection Principle	Electrochemical, Infrared, Catalytic Bead
Gases Detected	Combustible gases, toxic gases, and oxygen
Display	LCD with backlight
Humidity Range	0 to 99% RH (non-condensing)
Housing Material	Stainless steel
Output Signal	4-20 mA, HART, RS-485 Modbus
Power Supply	10 to 30 V DC
Certifications	ATEX, IECEx, CSA
Temperature Range	-40 °C to +65 °C (depending on sensor)
