Dräger Polytron 8000 Series Technical Manual

Technical Manual | Dräger Polytron
®
8000 Series 95
Accessories and spare parts
19.3.1 Sensors
19.4 Polytron
®
8310 IR
19.4.1 Sensors
19.5 Polytron
®
87x0 IR
Calibration adapter PE, Europe 6806978
Remote Calibration Adapter DQ 6812480
Remote Calibration Adapter LC
1)
6812482
1) Remote Calibration Adapter LC is not covered by performance approval.
Description Part Number
Description Part number
DrägerSensor DQ NPT 6814150
DrägerSensor LC NPT 6810675
Sensing head, Polytron SE Ex PR M1
DQ
6812711
Sensing head, Polytron SE Ex PR M2
DQ
6812710
Sensing head, Polytron SE Ex HT M DQ 6812720
Description Part Number
Splash Guard 6810796
Process Adapter 6811330
Protection Labyrinth 6811135
Calibration adapter 6810859
PCB unit Polytron 8310
4-20/HART
4544788
PCB unit Polytron 8310
4-20/HART Relay
4544789
Description Part number
DrägerSensor IR NPT 6811901
Sensing head, DrägerSensor IR
complete set e
6811165
Sensing head, DrägerSensor IR
complete set e2
6811265
Description Part Number
PCB unit Polytron 87x0
4-20/HART
1)
4544795
PCB unit Polytron 87x0
4-20/HART Relay
1)
4544796
Mounting Set PIR 7000 6811648

Dräger Polytron 8000 Series Specifications

General

Ingress Protection	IP66/67
Detection Principle	Electrochemical, Infrared, Catalytic Bead
Gases Detected	Combustible gases, toxic gases, and oxygen
Display	LCD with backlight
Humidity Range	0 to 99% RH (non-condensing)
Housing Material	Stainless steel
Output Signal	4-20 mA, HART, RS-485 Modbus
Power Supply	10 to 30 V DC
Certifications	ATEX, IECEx, CSA
Temperature Range	-40 °C to +65 °C (depending on sensor)
