Draytek Vigor2860 Series User Manual

Vigor2860 Series User’s Guide
143
For Vigor2860n-plus series, the web page will be shown as follows:
Note: Settings in this page only applied to LAN port but not WAN port.
Available settings are explained as follows:
Item Description
Enable
Click it to enable VLAN configuration.
LAN
P1 – P6 – Check the LAN port(s) to group them under the
selected VLAN.
Wireless LAN (2.4GHz)
SSID1 – SSID4 – Check the SSID boxes to group them
under the selected VLAN.
Wireless LAN (5GHz)
SSID1 – SSID4 – Check the SSID boxes to group them
under the selected VLAN.
Subnet
Choose one of them to make the selected VLAN mapping
to the specified subnet only. For example, LAN1 is
specified for VLAN0. It means that PCs grouped under
VLAN0 can get the IP address(es) that specified by the
subnet.

Draytek Vigor2860 Series Specifications

General

Firewall Type	Stateful Packet Inspection (SPI)
VPN Support	IPSec, PPTP, L2TP, SSL VPN
DoS Protection	Yes
Intrusion Prevention System (IPS)	Yes
LAN Interfaces	4 x Gigabit Ethernet
User Authentication	Local, RADIUS, LDAP
VPN Tunnels	32
Management Interface	Web-based, CLI
Concurrent Sessions	50, 000
Content Filtering	URL Keyword Filtering, Web Content Filtering
