Draytek Vigor2860 Series User Manual

Vigor2860 Series User’s Guide
149
3
3
.
.
2
2
.
.
7
7
W
W
i
i
r
r
e
e
d
d
8
8
0
0
2
2
.
.
1
1
x
x
IEEE 802.1x is an IEEE Standard for port-based Network Access Control (PNAC). It is part
of the IEEE 802.1 group of networking protocols. It provides an authentication mechanism for
the device that is attached to a LAN or WLAN.
Wired 802.1x provides authentication for one network device on each LAN port. The
RADIUS Server settings must be configured before enabling 802.1x because the EAP
(Extensible Authentication Protocol) Authenticator relies on the RADIUS Server in its
authentication process. Each LAN port with Wired 802.1x configured will only forward
802.1x packets and block all other packets until the authentication has successfully completed.
Available settings are explained as follows:
Item Description
Enable
Check the box to enable LAN 802.1x function.
802.1x ports
After enabling the function, simply specify the LAN port(s) to
apply such function.
After finishing all the settings here, please click OK to save the configuration.

Draytek Vigor2860 Series Specifications

General

Firewall Type	Stateful Packet Inspection (SPI)
VPN Support	IPSec, PPTP, L2TP, SSL VPN
DoS Protection	Yes
Intrusion Prevention System (IPS)	Yes
LAN Interfaces	4 x Gigabit Ethernet
User Authentication	Local, RADIUS, LDAP
VPN Tunnels	32
Management Interface	Web-based, CLI
Concurrent Sessions	50, 000
Content Filtering	URL Keyword Filtering, Web Content Filtering
