Vigor2860 Series User’s Guide
704
Port number 1 is locked for NAT usage.
Keep Tag
It means Multi-VLAN packets will keep their VLAN headers
to LAN.
E
E
x
x
a
a
m
m
p
p
l
l
e
e
PVC 7 will map to LAN port 2/3/4 in bridge mode; service type is Normal. No tag added.
> > wan mvlan 7 on p2 p3 p4
PVC Bridge p1 p2 p3 p4 p5 p6 Service Type Tag Priority Keep Tag
------------------------------------------------------------------
7 ON 0 0 1 1 0 0 Normal 0(OFF) 0 OFF
>
T
T
e
e
l
l
n
n
e
e
t
t
C
C
o
o
m
m
m
m
a
a
n
n
d
d
:
:
w
w
a
a
n
n
m
m
u
u
l
l
t
t
i
i
f
f
n
n
o
o
This command allows you to specify a channel (in Multi-PVC/VLAN) to make bridge
connection to a specified WAN interface.
wan multifno [channel #] [WAN interface #]
wan multifno status
S
S
y
y
n
n
t
t
a
a
x
x
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
Parameter Description
channel #
There are 4 (?) channels including VLAN and PVC.
Available settings are:
1=Channel 1
3=Channel 3
4=Channel 4
5=Channel 5
WAN interface #
Type a number to indicate the WAN interface.
1=WAN1
status
It means to display current bridge status.
E
E
x
x
a
a
m
m
p
p
l
l
e
e
> wan multifno 5 1
% Configured channel 5 uplink to WAN1
> wan multifno status
% Channel 3 uplink ifno: 3
% Channel 4 uplink ifno: 3
% Channel 5 uplink ifno: 3
% Channel 6 uplink ifno: 3
% Channel 7 uplink ifno: 3
>
