Vigor2860 Series User’s Guide
290
Pre-Shared Key - Check the box of Pre-Shared Key to
invoke this function and type in the required characters
(1-63) as the pre-shared key.
Digital Signature (X.509) – Check the box of Digital
Signature to invoke this function and Select one predefined
Profiles set in the VPN and Remote Access >>IPsec Peer
Identity.
IPsec Security Method
This group of fields is a must for IPsec Tunnels and L2TP
with IPsec Policy when you specify the remote node. Check
the Medium, DES, 3DES or AES box as the security
method.
Medium-Authentication Header (AH) means data will be
authenticated, but not be encrypted. By default, this option
is invoked. You can uncheck it to disable it.
High-Encapsulating Security Payload (ESP) means
payload (data) will be encrypted and authenticated. You
may select encryption algorithm from Data Encryption
Standard (DES), Triple DES (3DES), and AES.
Local ID (Optional)- Specify a local ID to be used for
Dial-in setting in the LAN-to-LAN Profile setup. This item
is optional and can be used only in IKE aggressive mode.
After finishing all the settings here, please click OK to save the configuration.
3
3
.
.
1
1
1
1
.
.
6
6
L
L
A
A
N
N
t
t
o
o
L
L
A
A
N
N
Here you can manage LAN-to-LAN connections by maintaining a table of connection profiles.
You may set parameters including specified connection direction (dial-in or dial-out),
connection peer ID, connection type (VPN connection - including PPTP, IPsec Tunnel, and
L2TP by itself or over IPsec) and corresponding security methods, etc.
The router supports up to 32 VPN tunnels simultaneously. The following figure shows the
summary table.
The following figure shows the summary table according to the item (All/Trunk) selected for
View.
