Vigor2860 Series User’s Guide
703
Parameter Description
wan1/wan2
It means to specify which WAN will be applied with load
balance.
on
It means to make WAN interface as the member of load
balance.
off
It means to cancel WAN interface as the member of load
balance.
E
E
x
x
a
a
m
m
p
p
l
l
e
e
> wan lb status
WAN1: on
WAN2: on
WAN3: on
WAN4: on
WAN5: on
WAN6: on
WAN7: on
T
T
e
e
l
l
n
n
e
e
t
t
C
C
o
o
m
m
m
m
a
a
n
n
d
d
:
:
w
w
a
a
n
n
m
m
v
v
l
l
a
a
n
n
This command allows you to configure multi-VLAN for WAN and LAN. It supports pure
bridge mode (modem mode) between Ethernet WAN and LAN port 2~4.
wan mvlan [pvc_no/status/save/enable/disable] [on/off/clear/tag tag_no] [service type/vlan
priority] [px ... ][ Keep Tag]
S
S
y
y
n
n
t
t
a
a
x
x
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
Parameter Description
pvc_no
It means index number of PVC. There are 10 PVC,
0(Channel-1) to 9(Channel-9) allowed to be configured.
However, only 2 to 9 are available for configuration.
status
It means to display the whole Bridge status.
save
It means to save the configuration into flash of Vigor router.
enable/disable
It means to enable/disable the Multi-VLAN function.
on/off
It means to turn on/off bridge mode for the specific channel.
clear
It means to turn off/clear the port.
tag tag_no
It means to tag a number for the VLAN.
-1: No need to add tag number.
1-4095: Available setting numbers used as tagged number.
service type
It means to specify the service type for VLAN.
0: Normal.
1: IGMP.
vlan priority
It means to specify the priority for the VALN setting.
Range is from 0 to 7.
px
It means LAN port. Available setting number is from 2 to 4.
