Vigor2860 Series User’s Guide
369
keypad on the phone.
OutBand - Choose this one then the Vigor will
capture the keypad number you pressed and transform
it to digital form then send to the other side; the
receiver will generate the tone according to the digital
form it receive. This function is very useful when the
network traffic congestion occurs and it still can
remain the accuracy of DTMF tone.
SIP INFO- Choose this one then the Vigor will
capture the DTMF tone and transfer it into SIP form.
Then it will be sent to the remote end with SIP
message.
Payload Type (rfc2833) - Type a number from 96 to 127,
the default value was 101. This setting is available for the
OutBand (RFC2833) mode.
3
3
.
.
1
1
5
5
.
.
4
4
S
S
t
t
a
a
t
t
u
u
s
s
From this page, you can find codec, connection and other important call status for each port.
Available settings are explained as follows:
Item Description
Refresh Seconds
Specify the interval of refresh time to obtain the latest VoIP
calling information. The information will update
immediately when the Refresh button is clicked.
Port
It shows current connection status for Phone(s) ports.
