Draytek Vigor2860 Series User Manual

Vigor2860 Series User’s Guide
28
Port Color
Displayed
Explanation
Black It means the router or the function is not working. LED (left side)
Green It means the router or the function is working.
Black It means no USB device is connected. USB
Green It means a USB device is connected.
Black xDSL connection is not ready.
Green It means WAN1 VDSL broadband access is available.
VDSL/ADSL
Orange It means WAN1 ADSL broadband access is available.
Black No Etherenet connection.
Orange It means WAN2 broadband access is available and port
link rate does not reach 1Gbps.
WAN2(Giga)
Green It means WAN2 broadband access is available and port
link rate reaches 1Gbps.
Black It means such port is disconnected. GigaLAN1~6
Green It means such port is connected physically.
For detailed information about the LED display, refer to 1.2 LED Indicators and
Connectors.
1
1
.
.
7
7
.
.
2
2
N
N
a
a
m
m
e
e
w
w
i
i
t
t
h
h
a
a
L
L
i
i
n
n
k
k
A name with a link (e.g., Router Name, Current Time, WAN1~4 and etc.) below means you
can click it to open the configuration page for modification.

Draytek Vigor2860 Series Specifications

General

Firewall Type	Stateful Packet Inspection (SPI)
VPN Support	IPSec, PPTP, L2TP, SSL VPN
DoS Protection	Yes
Intrusion Prevention System (IPS)	Yes
LAN Interfaces	4 x Gigabit Ethernet
User Authentication	Local, RADIUS, LDAP
VPN Tunnels	32
Management Interface	Web-based, CLI
Concurrent Sessions	50, 000
Content Filtering	URL Keyword Filtering, Web Content Filtering
