Vigor2860 Series User’s Guide
39
2
2
.
.
1
1
.
.
1
1
F
F
o
o
r
r
W
W
A
A
N
N
1
1
(
(
A
A
D
D
S
S
L
L
/
/
V
V
D
D
S
S
L
L
2
2
)
)
WAN1 is specified for ADSL or VDSL2 connection.
Available settings are explained as follows:
Item Description
Display Name
Type a name to identify such WAN.
DSL Mode
Specify the physical mode (VDSL2 only or ADSL only) for
such router manually.
VLAN Tag insertion
(VDSL2)/(ADSL)
The settings configured in this field are available for WAN1
and WAN2.
Enable – Enable the function of VLAN with tag.
The router will add specific VLAN number to all packets on
the WAN while sending them out.
Please type the tag value and specify the priority for the
packets sending by WAN1.
Disable – Disable the function of VLAN with tag.
Tag value – Type the value as the VLAN ID number. The
range is form 0 to 4095.
Priority – Type the packet priority number for such VLAN.
The range is from 0 to 7.
You have to select the appropriate Internet access type according to the information from
your ISP. For example, you should select PPPoE mode if the ISP provides you PPPoE
interface. In addition, the field of For ADSL Only will be available only when ADSL is
detected. Then click Next for next step.
