Draytek Vigor2860 Series User Manual

Vigor2860 Series User’s Guide
169
Item Description
Choose Private IP or Active True IP first.
Active True IP selection is available for WAN1 only.
Private IP
Enter the private IP address of the DMZ host, or click Choose
PC to select one.
Choose PC
Click this button and then a window will automatically pop
up, as depicted below. The window consists of a list of private
IP addresses of all hosts in your LAN network. Select one
private IP address in the list to be the DMZ host.
When you have selected one private IP from the above dialog,
the IP address will be shown on the following screen. Click
OK to save the setting.
DMZ Host for WAN2, WAN3 or WAN4 is slightly different with WAN1. Active True IP
selection is available for WAN1 only.
See the following figure.

Draytek Vigor2860 Series Specifications

General

Firewall Type	Stateful Packet Inspection (SPI)
VPN Support	IPSec, PPTP, L2TP, SSL VPN
DoS Protection	Yes
Intrusion Prevention System (IPS)	Yes
LAN Interfaces	4 x Gigabit Ethernet
User Authentication	Local, RADIUS, LDAP
VPN Tunnels	32
Management Interface	Web-based, CLI
Concurrent Sessions	50, 000
Content Filtering	URL Keyword Filtering, Web Content Filtering
