Vigor2860 Series User’s Guide
201
automatically by the router.
Alert Tool – If it is selected, the user can open Alert Tool
and type the user name and password for authentication. A
window with remaining time of connection for such user
will be displayed. Next, the user can access Internet through
any browser on Windows. Note that Alert Tool can be
downloaded from DrayTek web site.
Telnet – If it is selected, the user can use Telnet command
to perform the authentication job.
Landing Page
When a user tries to access into the web user interface of
Vigor router series with the user name and password
specified in this profile, he/she will be lead into the web
page configured in Landing Page field in User
Management>>General Setup.
Check this box to enable such function.
Index (1-15) in Schedule
Setup
You can type in four sets of time schedule for your request.
All the schedules can be set previously in Application >>
Schedule web page and you can use the number that you
have set in that web page.
Enable Time Quota
Time quota means the total connection time allowed by the
router for the user with such profile. Check the box to
enable the function of time quota. The first box displays the
remaining time of the network connection. The second box
allows to type the number of time (unit is minute) which is
available for the user (using such profile) to access Internet.
– Click this box to set and increase the time quota for
such profile.
– Click this box to decrease the time quota for such
profile.
Note: A dialog will be popped up to notify how many
time remained when a user accesses into Internet
through Vigor router successfully.
When the time is up, all the connection jobs including
network, IM, social media, facebook, and etc. will be
terminated.
Enable Data Quota
Data Quota means the total amount for data transmission
allowed for the user. The unit is MB/GB.
