Vigor2860 Series User’s Guide
206
Index
Display the profile number that you can configure.
Name
Display the name of the object profile.
To set a new profile, please do the steps listed below:
1. Click the number (e.g., #1) under Index column for configuration in details.
2. The configuration page will be shown as follows:
Available settings are explained as follows:
Item Description
Name
Type a name for this profile. Maximum 15 characters are
allowed.
Interface
Choose a proper interface.
For example, the Direction setting in Edit Filter Rule will
ask you specify IP or IP range for WAN or
LAN/DMZ/RT/VPN or any IP address. If you choose
LAN/DMZ/RT/VPN as the Interface here, and choose
LAN/DMZ/RT/VPN as the direction setting in Edit Filter
Rule, then all the IP addresses specified with
LAN/DMZ/RT/VPN interface will be opened for you to
choose in Edit Filter Rule page.
Address Type
Determine the address type for the IP address.
Select Single Address if this object contains one IP address
only.
Select Range Address if this object contains several IPs
within a range.
Select Subnet Address if this object contains one subnet
for IP address.
Select Any Address if this object contains any IP address.
Select Mac Address if this object contains Mac address.
