Vigor2860 Series User’s Guide
292
Available settings are explained as follows:
Item Description
View
All – Click it to display the LAN to LAN profiles.
Trunk – Click it to display the Trunk profiles.
Set to Factory Default
Click to clear all indexes.
Name
Indicate the name of the LAN-to-LAN profile. The
symbol ??? represents that the profile is empty.
Active
V – means the profile has been enabled.
X – mans the profile has not been enabled.
Status
Indicate the status of individual profiles. The symbol V and
X represent the profile to be active and inactive,
respectively.
To edit each profile:
1. Click each index to edit each profile and you will get the following page. Each
LAN-to-LAN profile includes 4 subgroups. If the fields gray out, it means you may leave
it untouched. The following explanations will guide you to fill all the necessary fields.
For the web page is too long, we divide the page into several sections for explanation.

Draytek Vigor2860 Series Specifications

General

Firewall Type	Stateful Packet Inspection (SPI)
VPN Support	IPSec, PPTP, L2TP, SSL VPN
DoS Protection	Yes
Intrusion Prevention System (IPS)	Yes
LAN Interfaces	4 x Gigabit Ethernet
User Authentication	Local, RADIUS, LDAP
VPN Tunnels	32
Management Interface	Web-based, CLI
Concurrent Sessions	50, 000
Content Filtering	URL Keyword Filtering, Web Content Filtering
