Draytek Vigor2860 Series User Manual

Vigor2860 Series User’s Guide
301
when you find there are several subnets behind the remote
VPN router.
Translated Type – There are two types for you to choose.
 Whole Subnet
 Specific IP Address
Virtual IP Mapping – A pop up dialog will appear for you
to specify the local IP address and the mapping virtual IP
address.
2. After finishing all the settings here, please click OK to save the configuration.

Draytek Vigor2860 Series Specifications

General

Firewall Type	Stateful Packet Inspection (SPI)
VPN Support	IPSec, PPTP, L2TP, SSL VPN
DoS Protection	Yes
Intrusion Prevention System (IPS)	Yes
LAN Interfaces	4 x Gigabit Ethernet
User Authentication	Local, RADIUS, LDAP
VPN Tunnels	32
Management Interface	Web-based, CLI
Concurrent Sessions	50, 000
Content Filtering	URL Keyword Filtering, Web Content Filtering
