Vigor2926 Series User’s Guide
873
0 – any
1 – ICMP
2 – IGMP
6 – TCP
17 – UDP
255 – TCP/UDP
Frag – “ON” means to bind the fragmented packet; “OFF” means
not to care. It is the default setting.
bind insert
<After_BindIndex> <ACT>
<TrunkName> <Member>
<SrcIp:A~B> <DstIp:A~B>
<DstPort:A~B> <Proto>
<Frag>
It is used to insert additional load balance policy into an existing
policy.
After_BindIndex – Specify an index number that new additional
policy should be inserted before. See the following example:
vpn trunk bind insert 1 y vpnlb 2
192.168.10.3~192.168.10.200
192.168.99.200~192.168.99.200 80~80 TCP OFF
ACT – Specify the action. “y” means active; “n” means inactive or
delete.
TrunkName - Specify the name of the VPN trunk.
Member – Specify the index number of the LAN to LAN (dial-out)
profile to be bound.
SrcIp:A~B – Specify the source IP range (e.g.,
192.168.10.0~192.168.10.255.
DstI p:A~B - Specify the destination IP range (e.g.,
192.168.1.0~192.168.1.255.
DstPort:A~B – Specify the destination port range (1~65535).
Proto – Specify the protocol.
0 – any
1 – ICMP
2 – IGMP
6 – TCP
17 – UDP
255 – TCP/UDP
Frag – “ON” means to bind the fragmented packet; “OFF” means
not to care. It is the default setting.
SetGre show
<Dialout_Index>
Display the GRE over IPSec settings in specified LAN to LAN profile.
Dialout_Index – Index number of the LAN to LAN (dial-out) profile.
SetGre
<Active/In-active><Dialout_I
ndex><GRE_MyIP><GRE_Pee
rIP><Logical_Traffic>
Active/In-active - Specify the action. “y” means active; “n” means
inactive.
Dialout_Index – Index number of the LAN to LAN (dial-out) profile.
GRE_MyIP –Type the virtual IP for router itself for verified by peer.
GRE_PeerIP –Type the virtual IP of peer host for verified by router.
Logical_Traffic - Specify the action for RFC2890. “y” means active;
“n” means inactive.
An_Gre GreIPsecAnalyze
<ON/OFF>
These commands are used for RD debug.
E
E
x
x
a
a
m
m
p
p
l
l
e
e
> vpn setup 1 name1 pptp_out 1.2.3.4 vigor 1234 192.168.1.0 255.255.255.0
% Profile Change Log ...
% Profile Index : 1
% Profile Name : name1j
% Username : vigor
% Password : 1234
% Call Direction : Dial-Out
% Type of Server : PPTP
