DSE DSE5510 User Manual

DSE Model 5510 Autostart Control and Instrumentation System Operators Manual
057-015 5510 OPERATING MANUAL ISSUE 11 07/07/09 AM 76
Device Description
52 ac circuit breaker
A device that is used to close and interrupt an ac power circuit under normal
conditions or to interrupt this circuit under fault or emergency conditions.
54
turning gear
engaging device
A device electrically operated, controlled, or monitored that functions to
cause the turning gear to engage (or disengage) the machine shaft.
55 power factor relay
A device that o
perates when the power factor in an ac circuit rises above or
falls below a predetermined value.
59 overvoltage relay
A device that operates when its input voltage exceeds a predetermined
value.
62
time-delay stopping
or opening relay
A device that imposes a time delay in conjunction with the device that
initiates the shutdown, stopping, or opening operation in an automatic
sequence or protective relay system.
63 pressure switch
A device that operates at a given pressure value or at a given rate of
change of pressure.
69
permissive control
device
A device with two-positions that in one position permits the closing of a
circuit breaker, or the placing of a piece of equipment into operation, and in
the other position, prevents the circuit breaker or the equipment from being
operated.
71 level switch
A device that operates at a given level value, or on a given rate of change
of level.
74 alarm relay
A device other than an annunciator, as covered under device function 30,
that is used to operate, or that operates in connection with, a visual or
audible alarm.
78
phase-angle
measuring relay
A device that functions at a predetermined phase angle between two
voltages, between two currents, or between voltage and current.
81 frequency relay
A device that responds to the frequency of an electrical quantity, operating
when the frequency or rate of change of frequency exceeds or is less than
a predetermined value.
83
automatic selective
control or transfer
relay
A device that operates to select automatically between certain sources or
conditions in equipment or that performs a transfer operation automatically.
86 lockout relay
A device that trips and maintains the associated equipment or devices
inoperative until it is reset by an operator, either locally or remotely.
90 regulating device
A device that functions to regulate a quantity or quantities, such as voltage,
current, power, speed, frequency, temperature, and load, at a certain value
or between certain (generally close) limits for machines, tie lines, or other
apparatus.

DSE DSE5510 Specifications

General

Model	DSE5510
Max. Operating Current	340 mA at 12 V, 160 mA at 24 V
Max. Standby Current	160 mA at 12 V, 80 mA at 24 V
Magnetic Input Frequency	10, 000 Hz (max)
Operating Temperature Range	-30°C to +70°C
Storage Temperature Range	-40°C to +85°C
Type	Auto Start Control Module
Display	LCD
Input Voltage	8 V to 35 V DC
Cranking Dropouts	Able to survive 0 V for 50 ms providing the supply was at least 10 V before dropout and recovers to 5 V afterwards
Alternator Input Range	15 V AC (Ph-N)
Magnetic Input Range	0.5 V to 70 V
Operating Temperature	+70°C
Protection Class	IP65
