DSE Model 5510 Autostart Control and Instrumentation System Operators Manual
057-015 5510 OPERATING MANUAL ISSUE 11 07/07/09 AM 40
5.4.4 LIST OF ADJUSTABLE PARAMETERS IN ‘APPLICATION EDITOR’
(Factory default settings are shown in bold italicised text)
Section Parameter as shown on display Values
Application settings
Language
ENGLISH
ENGLISHENGLISH
ENGLISH
, OTHERS
(see note below)
Alternative Frequency
Enable/Disable
Alternative voltage
Enable/Disable
AC System
3 phase, 4wire
Single phase, 2 wire
3 phase, 3 wire
2 phase, 2wire L1& L2
3 phase, 4 wire ED
2 phase 2 wire L1 & L3
Generator Full load rating
300-600A (500A)
Droop
Enable/Disabled
Contrast
|
Date and Time
dd mmm yyyy hh:mm
Generator run priority
1-16 (1)
Auto Scroll Time
0-10s (2.0s)
Generator CT Primary Rating
5-6000A (600A)
Generator CT Secondary Rating
1A / 5A
Mains CT Primary Rating
1A / 5A
Generator Control Full kW rating
1-5000kW (345kW)
Generator Control Full kVAr rating
1-5000kVAr (258kW)
Load ramp rate
0.1-100% (3%)
Load level for more sets
0-100% (80%)
Load level for less sets
0-100% (70%)
Load Parallel Power
0-100% (50% 172Kw)
Load Power Factor
01-1.00-01 (1.00pf)
Enable commissioning screens Yes, No
Override starting alarms Yes, No
Voltage adjust (manual mode only engine running breaker open) 0-100 % (0)
Frequency adjust (manual mode only engine running breaker open) 0-100 % (0)
Enable mains decoupling test mode (Off mode only) Yes-No
Abandon changes and exit
Save changes and exit
NOTE:- More comprehensive module configuration is possible using the 5xxx series PC
configuration software in conjunction with the P810 PC interface. Please contact us for
further details.
NOTE:- Languages are subject to change as the modules are updated. Please contact
us for the list of latest supported languages.
