DSE Model 5510 Autostart Control and Instrumentation System Operators Manual
057-015 5510 OPERATING MANUAL ISSUE 11 07/07/09 AM 32
5.1.2 TYPICAL INSTRUMENT DISPLAY
Engine oil pressure
The display of the engine oil pressure
6.2
Bar
90 Psi
620
KPa
Coolant temperature The display of the engine coolant temperature
74
°C
165 °F
Generator Amps
The display of all three generator line currents.
L1 50A
L2 52A
L3 50A
Mains
ROCOF / Vector shift display (For systems configured to parallel
with mains supply only)
Present values are shown to the left with the ‘peak hold’ values
shown on the right.
ROCOF 0.2Hz
Vector 1.4°
10Hz
2°
5.1.3 TYPICAL ALARM DISPLAY
Alarm The module is warning that the engine oil pressure has fallen below
a pre set level. The generator is not shutdown.
Warning
Low oil pressure
Alarm The oil pressure has fallen below a second pre set value and has
shutdown the generator.
Shutdown
Low oil pressure
Alarm The module is warning that the battery voltage is below a pre set
value.
Warning
Low battery Volts
