DSE Model 5510 Autostart Control and Instrumentation System Operators Manual
057-015 5510 OPERATING MANUAL ISSUE 11 07/07/09 AM 56
10 SPECIFICATION
DC Supply Continuous voltage rating :
8V to 35V
Cranking dip protection :
Able to survive 0V for 50mS, providing supply was at least 10V before dropout and supply recovers
to 5V. This is achieved without the need for internal batteries
Charge Fail/ Excitation:
0V to 35V fixed power source 25W
Max. Standby Current:
375mA at 12V. 200mA at 24V.
Max. Operating Current:
460mA at 12V. 245mA at 24V
Alternator Input Range:
5V - 277(ph-N) (+20%) 50Hz - 60Hz (Minimum 15V AC Ph-N)
Accuracy:
1% of full scale True RMS sensing
Supported topologies:
3 Phase 4wire Wye
3 phase 3 wire Delta
3 phase 3 wire Edison Delta
Single phase 2 wire
2 Phase 3wire L1 & L2
2 Phase 3 wire L1 & L3
Bus Input Range:
15V - 277(ph-N) (+20%) 50Hz - 60 Hz
Accuracy:
1% of full scale True RMS sensing
Supported topologies:
3 Phase 4wire Wye
3 phase 3 wire Delta
3 phase 3 wire Edison Delta
Single phase 2 wire
2 Phase 3wire L1 & L2
2 Phase 3 wire L1 & L3
CT’s Burden:
0.5VA
Primary rating:
1A - 6000A (user selectable)
Secondary rating:
1A or 5A secondary (user selectable)
Accuracy of measurement:
1% of full load rating (when using 0.5% or better CTs with 5A secondary winding) Lower class CTs
will reduce the overall accuracy of the reading.
Recommendations:
Class 1 required for instrumentation
Protection class required if using for protection.
Magnetic Pickup Voltage range :
+/- 0.5V minimum (during cranking) to 70V Peak
Frequency range:
10,000 Hz (max)
Relay outputs Fuel:
16 Amp DC at supply voltage
Start:
16 Amp DC at supply voltage
Auxiliary outputs 1,2,3:
5 Amp DC at supply voltage
Output 4 (Generator loading relay)
Voltage free, normally open, 8 Amp 250V AC RMS rated
