DSE Model 5510 Autostart Control and Instrumentation System Operators Manual
057-015 5510 OPERATING MANUAL ISSUE 11 07/07/09 AM 7
3 OPERATION
3.1 CONTROL
Control of the DSE 5510 module is via push buttons mounted on the front of the module with
STOP/RESET, MANUAL, AUTO, ALARM MUTE/LAMP TEST and START functions. For normal
operation these are the only controls which need to be operated. The smaller push buttons are used
to access further information such as engine instruments and load switching. Detail of their operation
is covered later in this document.
The following descriptions detail the sequences followed by a module containing the standard
‘factory configuration’. Always refer to your configuration source for the exact sequences and timers
observed by any particular module in the field.
CAUTION: - The module may instruct an engine start event due to external influences.
Therefore, it is possible for the engine to start at any time without warning. Prior to
performing any maintenance on the system, it is recommended that steps are taken to
remove the battery and isolate supplies.
