DSE Model 5510 Autostart Control and Instrumentation System Operators Manual
057-015 5510 OPERATING MANUAL ISSUE 11 07/07/09 AM 38
5.4.2 EDITING VALUES
If the PIN number has not been set, or has been correctly entered :
Operation Detail
The LCD will then display:
CONFIGURATION
To view the different configuration functions press the + or - buttons.
The LCD will then display the first item:
(example)
CONFIGURATION
Oil Pressure
Pre-alarm
1.30 Bar 18 PSI 130 kPa
button will enter edit mode :
The parameter being changed will flash.
Pressing + or – buttons will change the parameter to the
desired value.
CONFIGURATION
Oil Pressure
Pre-alarm
1.30 Bar 18 PSI 130 kPa
Press to save the change. The parameter will stop flashing as the edit mode is exited.
To view the different configuration functions press the + or - buttons.
For date and time editing only: press to select between day, month, year, hours and minutes.
To exit the ‘Operator configuration mode’ save your
current value change if you haven’t already done so
(press to exit the flashing edit mode), then press
Stop/Reset to exit configuration mode.
The module will then return to the ‘Status Page’ display.
To Next Page
