4 PROTECTIONS
When an alarm is present the Audible Alarm will sound and the Common alarm LED (if configured)
will illuminate.
The audible alarm can be silenced by pressing the ‘Mute’ button
The LCD display will jump from the ‘Information page’ to display the Alarm Page
Alarm
Warning
Low oil pressure
The type of alarm. Shutdown or warning
The nature of alarm, e.g. Low oil pressure.
The LCD will display multiple alarms e.g. “High Engine Temperature shutdown”, “Emergency Stop”
and “Low Coolant Warning” alarms that may have been triggered. These will automatically scroll
round in the order that they occurred.
In the event of a warning alarm the LCD will display the appropriate text. If a shutdown then occurs
the module will again display the appropriate text.
Example:-
Alarm
Shutdown
High coolant temp
Followed by….
Alarm
Shutdown
Emergency stop
Followed by….
Alarm
Warning
Low coolant level
The unit will scroll through
all active alarms in a
continuous loop.
Alarm
Shutdown
High coolant temp
Generator available
L-N 229v 0A
If no alarms are present the LCD
will display this default page.
L-L 400 v 50.0Hz
Pf 0.00 0KW
To Next Page
