5.2 VIEWING THE INSTRUMENT AND EVENT LOG PAGES
To view a particular instrument, operate the “Page” button to move to the required page.
The LCD will display the page title and then will automatically commence scrolling down the various
instruments. On reaching the last instrument, the LCD display will then jump back to the page title
and resume scrolling down the page. This sequence will be repeated until either the user moves off
the page, the LCD page timer has expired or an alarm condition occurs. In the case of the latter, the
module will jump to the alarm page to show the relevant alarm details.
Engine speed
0 RPM
Engine oil pressure
6.2
Bar
90 Psi
620
KPa
Coolant temperature
74
°C
165 °F
Etc….
It is also possible to scroll to display the different instruments using and buttons. Once
selected the instrument will remain on the LCD display until the user selects a different instrument or
page, or after a period of inactivity, the module will revert to the ‘Status page’.
NOTE:-This description of operation is also true for the other instrument pages and for
viewing the records in the event log.
NOTE:- The factory default setting is to show all instruments in a single list. It is
possible to change this configuration to a “page” style display using the 5xxx configuration
software. When configured to the page style, the instruments are grouped into separate
pages – i.e. Engine instruments, Gen instruments, bus instruments.
