DSE Model 5510 Autostart Control and Instrumentation System Operators Manual
057-015 5510 OPERATING MANUAL ISSUE 11 07/07/09 AM 49
9.1.3 PLUG “C” 9 WAY
PIN
No
DESCRIPTION CABLE
SIZE
NOTES
20 Magnetic pickup screen 0.5mm Connect at module end only!
21 Magnetic pickup 0.5mm Connect to magnetic pickup device
22 Magnetic pickup 0.5mm Connect to magnetic pickup device
23 Electronic Engine ECU
Screen
0.5mm Connect screen at one end only
24 Electronic Engine ECU H 0.5mm 120
impedance CAN cable
25 Electronic Engine ECU L 0.5mm 120
impedance CAN cable
26 Multiset comms Link SCR 0.5mm Screen for multiset comms link (MSC)
27 Multiset comms Link H 0.5mm 120
impedance CAN cable
28 Multiset comms Link L 0.5mm 120
impedance CAN cable
NOTE:- Screened cable must be used for connecting the Magnetic Pickup, ensuring that
the screen is earthed at one end ONLY.
NOTE:- Screened 120
impedance cable specified for use with CANBUS must be used
for both the electronic engine link and the Multiset comms link.
DSE stock and supply Belden cable 9841 which is a high quality 120
impedance cable
suitable for CANbus use (DSE part number 016-030)
9.1.4 PLUG “D” 3 WAY
PIN
No
DESCRIPTION CABLE
SIZE
NOTES
29 RS485 SCREEN 0.5mm Screen for RS485
30 RS485 B 0.5mm 120
impedance RS485 cable
31 RS485 A 0.5mm 120
impedance RS485 cable
NOTE:- Screened 120
impedance cable specified for use with RS485 must be used.
DSE stock and supply Belden cable 9841 which is a high quality 120
impedance cable
suitable for CANbus use (DSE part number 016-030)
9.1.5 PLUG “E” 5 WAY
PIN
No
DESCRIPTION CABLE
SIZE
NOTES
32 Governor output B 0.5mm Connect to governor for speed/load control
33 Governor output A 0.5mm Connect to governor for speed/load control
34 Unused Do not connect
35 AVR output B 0.5mm Connect to governor for volts/VAr control
36 AVR output A 0.5mm Connect to governor for volts/VAr control
NOTE:- For details of connections to governors and AVRs, refer to the DSE Guide to
Synchronising Part 2.
