DSE Model 5510 Autostart Control and Instrumentation System Operators Manual
057-015 5510 OPERATING MANUAL ISSUE 11 07/07/09 AM 50
9.1.6 PLUG “F” 8 WAY
PIN
No
DESCRIPTION CABLE
SIZE
NOTES
37 Configurable Relay Normally
Closed Contact
2.5mm Can be used for generator load switch “open” or
“shunt trip” functionality if required.
38 Configurable Relay Normally
Closed Contact
2.5mm Can be used for generator load switch “open” or
“shunt trip” functionality if required.
39 Generator Loading Relay
Normally Open Contact
2.5mm Connect to generator contactor coil feed supply.
40 Generator Loading Relay
Normally Open Contact
2.5mm Connect to generator contactor coil.
41 Bus volts L1 1.0mm Connect to Bus L1
42 Bus volts L2 1.0mm Connect to Bus L2
43 Bus volts L3 1.0mm Connect to Bus L3
44 Bus volts N 1.0mm Connect to Mains N
NOTE:- If the 5510 module is not being used for synchronising, terminals 37,38,
41,42,43,44 should be left disconnected.
NOTE:- If the 5510 module is synchronising with a mains supply instead of generator
bus, then terminals 41,42,43,44 are used for mains supply monitoring.
CAUTION!:- Refer to Typical wiring Diagram for different wiring topologies.
9.1.7 PLUG “G” 4 WAY
PIN
No
DESCRIPTION CABLE
SIZE
NOTES
45 Generator volts L1 1.0mm Connect to Generator L1
46 Generator volts L2 1.0mm Connect to Generator L2
47 Generator volts L3 1.0mm Connect to Generator L3
48 Generator volts N 1.0mm Connect to Generator N
