DSE Model 5510 Autostart Control and Instrumentation System Operators Manual
057-015 5510 OPERATING MANUAL ISSUE 11 07/07/09 AM 60
12 FAULT FINDING
SYMPTOM POSSIBLE REMEDY
Unit is inoperative Check the battery and wiring to the unit. Check the DC
supply. Check the DC fuse.
Unit shuts down Check DC supply voltage is not above 35 Volts or below 9
Volts
Check the operating temperature is not above 55 °C.
Check the DC fuse.
Unit locks out on Emergency Stop If an Emergency Stop Switch is not fitted, ensure that a
positive is connected to the Emergency Stop input. Check
emergency stop switch is functioning correctly. Check
Wiring is not open circuit.
Intermittent Magnetic Pick-up sensor
fault
Ensure that Magnetic pick-up screen is only connected at
one end, if connected at both ends this enables the screen
to act as an aerial and will pick up random voltages.
Low oil Pressure fault operates after
engine has fired
Check engine oil pressure. Check oil pressure
switch/sender and wiring. Check configured polarity (if
applicable) is correct (i.e. Normally Open or Normally
Closed) or that sender is compatible with the 5510 Module.
High engine temperature fault
operates after engine has fired.
Check engine temperature. Check switch/sender and
wiring. Check configured polarity (if applicable) is correct
(i.e. Normally Open or Normally Closed) or that sender is
compatible with the 5520 Module.
Shutdown fault operates Check relevant switch and wiring of fault indicated on LCD
display. Check configuration of input.
Warning fault operates Check relevant switch and wiring of fault indicated on LCD
display. Check configuration of input.
Fail to Start is activated after pre-set
number of attempts to start
Check wiring of fuel solenoid. Check fuel. Check battery
supply. Check battery supply is present on the Fuel output
of the module. Check the speed sensing signal is present
on the 5520 inputs. Refer to engine manual.
Continuous starting of generator
when in AUTO
Check that there is no signal present on the “Remote Start”
input. Check configured polarity is correct.
Generator fails to start on receipt of
Remote Start signal or under mains
failure conditions.
Check Start Delay timer has timed out. If remote start fault,
check signal is on “Remote Start” input. Confirm input is
configured to be used as “Remote Start”.
Pre-heat inoperative Check wiring to engine heater plugs. Check battery supply.
Check battery supply is present on the Pre-heat output of
module. Check pre-heat has been selected in your
configuration.
Starter motor inoperative Check wiring to starter solenoid. Check battery supply.
Check battery supply is present on the Starter output of
module. Ensure that the Emergency Stop input is at battery
positive.
Engine runs but generator will not
take load
Check Warm up timer has timed out. Ensure generator load
inhibit signal is not present on the module inputs.
NOTE:- The above fault finding is provided as a guide check-list only. As it is possible
for the module to be configured to provide a wide range of different features always refer to
the source of your module configuration if in doubt.
