E
30
Rear brake pedal (fig. 23)
Push down on the pedal (1) with your foot to operate the
rear brake.
The system is hydraulically operated.
Gear change pedal (fig. 24)
The gear change pedal is at rest when in the central
position N, and automatically returns to the central
position. When in this position, light N (3, fig. 4) on
instrument panel is on.
The pedal can be moved:
down = push down on the pedal to engage 1st gear and to
shift down. The N light will go out.
up = lift the pedal to engage the 2nd gear and then the 3rd,
4 th, 5th and 6th gear.
Each time you move the pedal you will engage the next
gear.
1
fig. 23
N
2
3
4
5
6
1
fig. 24

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ducati 749R and is the answer not in the manual?

Ducati 749R Specifications

General IconGeneral
Bore x Stroke94 mm x 54 mm
Transmission6-speed
FrameTubular steel trellis frame
Exhaust2-1-2 system with catalytic converter and lambda probe
Final DriveChain; front sprocket 15; rear sprocket 39
Front Wheel Travel120 mm
Front Brakes2 x 320 mm semi-floating discs, 4-piston calipers
Rear Brakes245 mm disc, 2-piston caliper
Front Tyre120/70 ZR17
Rear Tyre180/55 ZR17
Engine TypeL-Twin cylinder, 4 valve per cylinder desmodromic
Power89 kW (121 hp) @ 10, 250 rpm
Torque84 Nm (62 lb-ft) @ 8, 500 rpm
Fuel InjectionElectronic fuel injection, 54 mm throttle bodies
Front Suspension43 mm upside-down fork
Rear SuspensionFully adjustable monoshock
Rear Wheel Travel128 mm
Wheelbase1, 420 mm
Fuel Capacity15.5 L (including 3.5 L reserve)
