Ducati 749R User Manual

E
37
Side stand (fig. 32)
Important
Before lowering the side stand, make sure that the
bearing surface is hard and flat.
Do not park on soft or pebbled ground or on asphalt melt
by the sun heat and similar or the motorcycle may fall over.
When parking in downhill road tracts, always park the
motorcycle with its rear wheel facing downhill.
To pull down the side stand, hold the motorcycle
handlebars with both hands and push down on the thrust
arm (1) with your foot until it is fully extended. Tilt the
motorcycle until the side stand is resting on the ground.
Warning
Do not sit on the motorcycle when it is supported on
the side stand.
To move the side stand to its rest position (horizontal
position), tilt the motorcycle to the right and, at the same
time, lift the thrust arm (1) with your foot.
Note
Check for proper operation of the stand mechanism
(two springs, one into the other) and the safety sensor (2)
at regular intervals.
Note
It is possible to start the engine with side stand down
and the gearbox in neutral. When starting the bike with a
gear engaged, pull the clutch lever (in this case the side
stand must be up).
2
1
fig. 32

Ducati 749R Specifications

General

Bore x Stroke	94 mm x 54 mm
Transmission	6-speed
Frame	Tubular steel trellis frame
Exhaust	2-1-2 system with catalytic converter and lambda probe
Final Drive	Chain; front sprocket 15; rear sprocket 39
Front Wheel Travel	120 mm
Front Brakes	2 x 320 mm semi-floating discs, 4-piston calipers
Rear Brakes	245 mm disc, 2-piston caliper
Front Tyre	120/70 ZR17
Rear Tyre	180/55 ZR17
Engine Type	L-Twin cylinder, 4 valve per cylinder desmodromic
Power	89 kW (121 hp) @ 10, 250 rpm
Torque	84 Nm (62 lb-ft) @ 8, 500 rpm
Fuel Injection	Electronic fuel injection, 54 mm throttle bodies
Front Suspension	43 mm upside-down fork
Rear Suspension	Fully adjustable monoshock
Rear Wheel Travel	128 mm
Wheelbase	1, 420 mm
Fuel Capacity	15.5 L (including 3.5 L reserve)
