Ducati 749R User Manual

E
76
Checking engine oil level (fig. 78)
Engine oil level can be checked through the sight glass
(1) provided on the clutch cover. When checking oil level,
the motorcycle should be upright and the engine cold.
Allow a few minutes for oil to settle to a steady level after
stopping the engine. Oil level should be between the
marks near the sight glass. Top up oil level with SHELL
Advance Ultra 4, if low. Undo the filler plug (2) and top up
to correct level. Refit the plug.
Important
Engine oil and oil filters must be changed by a Ducati
Dealer or Authorized Workshop at regular intervals, as
specified in the routine maintenance chart (see Warranty
Card).
Viscosity
SAE 10W-40
The other viscosity degrees indicated in the table can be
used if the local average temperature is within the limits
specified for that oil viscosity.
2
1
fig. 78
–10
Unigrade
Multigrade
0 10 20 30 40 C
40
20W–40 20W–50
15W–40 15W–50
10W–40
10W–30
10W
20W
20
30

Ducati 749R Specifications

General

Bore x Stroke	94 mm x 54 mm
Transmission	6-speed
Frame	Tubular steel trellis frame
Exhaust	2-1-2 system with catalytic converter and lambda probe
Final Drive	Chain; front sprocket 15; rear sprocket 39
Front Wheel Travel	120 mm
Front Brakes	2 x 320 mm semi-floating discs, 4-piston calipers
Rear Brakes	245 mm disc, 2-piston caliper
Front Tyre	120/70 ZR17
Rear Tyre	180/55 ZR17
Engine Type	L-Twin cylinder, 4 valve per cylinder desmodromic
Power	89 kW (121 hp) @ 10, 250 rpm
Torque	84 Nm (62 lb-ft) @ 8, 500 rpm
Fuel Injection	Electronic fuel injection, 54 mm throttle bodies
Front Suspension	43 mm upside-down fork
Rear Suspension	Fully adjustable monoshock
Rear Wheel Travel	128 mm
Wheelbase	1, 420 mm
Fuel Capacity	15.5 L (including 3.5 L reserve)
